Welding of shear connectors dia. 22 mm with PRO-I 2800 and GD 25 WMS on generators on a bridge construction site (power cable length 120 m)

Welding of shear connectors 22x150 and 22x200 on a bridge construction site

Stud welding unit PRO-I 2800
Power supply on the construction site via generators with a total of 400 kVA (power cable length 120 m)

Welding parameter monitoring of the stud welding unit PRO-I 2800

Welded shear connectors (work sample) after bending tests

Detailed view: shear connectors dia. 22 mm welded at the edge of the component

Detailed view: welded shear connectors dia. 22 mm
